Satin Gunsmoke Grey Vinyl Wrap (ECH02)

TeckWrap Gunmetal Grey reflects strength, precision, and modern industry. Designed for those who value reliability and bold presence wrap your vehicle and express confidence on every drive.

Stop dreaming about a head-turning finish and start driving one. The TeckWrap VCH-S Satin Chrome collection blends the smooth feel of satin with a striking liquid-metal shine, delivering a finish that stands out without the high maintenance of real chrome.

More than just a color change, this wrap enhances your vehicle’s appearance while protecting the original paint. Pair it with professional tools and protection films to achieve a flawless, showroom-level result.

Specifications:

Conformable and flexible hybrid material, designed for smooth and medium-curved surfaces.

• Total Film Thickness: 0.27 mm
• Release Liner Thickness: 0.13 mm
• Application Layer Thickness: 0.14 mm
• Film Type: Polymeric vinyl film with silver coating and air-release channels

Adhesive & Liner

• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant (viscosity 1000–3000 cps, thickness 12 μm dry)
• Release Liner: Felix Schoeller, double-side PE-coated Kraft with solventless silicone coating and air-release (ISO 9001, ISO 14001, OHSAS 18001)

Performance:

• Durability / Warranty: View Datasheet
• Release Force: 0.10 N/25 mm (Standard: 0.10–0.30)
• Initial Tack: 822 g/25 mm (Standard: 800–1500)
• 180° Peel Strength: 10.66 N/25 mm (Standard ≥ 6.8)
• Adhesion Strength: 70 (Standard ≥ 60, no shifting)

Durability Tests:

• High-Temperature Aging: No adhesive residue (65°C, 7 days)
• Low-Temperature Aging: No adhesive residue (-65°C, 10 days)
• Post-Heating Temperature: 90°C

Installation Guidelines:

• Application Temperature: +17°C to +18°C
• Service Temperature: -35°C to +35°C
• Tools: Standard squeegee with soft (wet) buffer
• Surface Compatibility: Smooth and medium-curved surfaces
• Directional: Yes
• Overlap Width: 3–4 mm

Storage:

• Shelf Life: 2 years
• Conditions: +10°C to +20°C, 50% humidity, original packaging, away from sunlight, clean and dry environment

Packaging:

• Roll Width: 152 cm
• Length: 18 m or 23 m

Important Notes

• Colors and finishes may vary, always check the physical swatch
• Use rolls from the same production lot for consistent color matching
• Handle metallized films carefully—avoid overstretching, crumpling, or excessive heat
• Film may scratch during installation or daily use; scratches are not covered under warranty
