Matte Metallic Charcoal Grey Vinyl Wrap (ECH03)

Minimalist and contemporary, TeckWrap Charcoal Grey reveals a unique look. It fully defines modernity, an excellent choice for the moderate and decent.

With a collection of 15 fancy colors, TeckWrap offers you this series of matte metallic vinyl wraps that give your vehicle a subtle look of metallic steel with a flat finish. As a proud supplier, TeckWrap has plenty of film selections with good conformability and durability. The material is stretchable enough to wrap every edge and recessed area easily. And the adhesive is safe without giving you any trouble when uninstalling. The better thing is that these vinyl wraps from TeckWrap are all high quality but at reasonable and affordable prices.

Specifications:

• Total Film Thickness: 0.28 mm
• Release Liner Thickness: 0.14 mm
• Application Layer Thickness: 0.14 mm
• Film Type: High-grade polymeric calendared vinyl film with air-release channels
• Series: 190 Series

Adhesive & Liner

• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant, viscosity 1000–3000 cps, thickness 12 μm dry
• Release Liner: Felix Schoeller / double-side PE coated Kraft, one side solventless silicone-coated, air release (ISO 9001, ISO 140001, OHSAS 18001)

Shelf Life: 3 years if stored at +10°C to +20°C, relative humidity 50%, in original package, away from direct sunlight, clean and dry place

Performance & Testing:

• Durability / Warranty: Click here for TeckWrap Datasheet
• Release Force (N/25mm): Standard 0.04–0.12 | Result 0.1 (23°C, 54% RH)
• Initial Tack (g/25mm): Standard 800–1500 | Result 1254 (23°C, 54% RH)
• 180° Peel Strength (N/25mm): Standard ≥7.85 | Result 11.17 (23°C, 54% RH)
• Adhesion Strength: Standard ≥60 | Result 70 (No shifting)
• Post Heating: 100°C
• Aging (65°C, 7 days): High-temperature release without adhesive residue
• Aging (-65°C, 10 days): Low-temperature release without adhesive residue

Installation Guidelines:

• Application Temperature: +17°C to +18°C
• Usage Temperature: -45°C to +45°C
• Tools Required: Soft squeegee with buffer
• Conformability: Flat and moderate curves, deep recesses with inlays
• Directional: Yes
• Overlap Width: 4–5 mm

Packaging:

• Roll Width: 152 cm
• Roll Length: 18 m

Important Notes

• Images, colors, and finishes are approximate; always check a physical color swatch
• Use rolls from the same production LOT to ensure consistent color coverage
• Scratches during application or daily use are not covered under warranty
